NewART+ PVC windows
NewART+ is a versatile construction system suitable for various projects, from renovations to new builds. Thanks to its three gaskets—one of which is a central sealing gasket—it not only improves thermal insulation and enhances noise reduction but also reduces the corrosion of metal hardware parts and extends their optimal performance lifespan.
With its slim frame and large glass surface area, it maximizes the use of natural light and solar energy. The internal core of the profiles is made from 100% recycled materials, which not only reduces material consumption but also minimizes the ecological footprint.
NewART+ also provides excellent sound insulation, lowers energy consumption, and perfectly aligns with environmental principles, combining technological advancement with sustainability.
What you should know about NewART+ model?
- Triple sealing – high thermal and sound insulation
- Slim frame and large glass area – more natural light
- Sustainable construction – core made of 100% recycled materials
Products that can be made of NewART+ model:
- Windows
- Balcony doors
- Terrace doors opening inwards or outwards, with a low aluminium threshold or a full-frame perimeter
- Interior doors opening inwards or outwards, with or without an aluminium threshold
- PSK and PS sliding systems
Technical parameters
| Standard complectation of NewART+ | Optional features | |
| Profile |
SALAMANDER proEvolution |
– |
| Frame colour | White and Standard colours on the exterior | Premium and Premium+ colour ranges (one-sided or both-sided finish options) |
| Frame shape | Flat shape | – |
| Glazing beads | Flat shape | – |
| Rubber gaskets | Black colour rubber gaskets | – |
| UPVC frame width | 72mm | – |
| Quantity of chambers in frame/ in sash | 5/5 | – |
| Steel reinforcement | Galvanized steel profiles | – |
| Glazing | ◆ Double glazing (24 mm) – one pane is low-emissivity glass; ◆ Triple glazing (44 mm) – two panes are low-emissivity glass. |
◆ Other double or triple glazed units with patterned, tinted, solar control, or obscure glass ◆ Decorative glazing bars fitted within the sealed unit or applied to the external surface of the glass |
| Seals | Triple (MD with central gasket) sealing with increased-thickness gaskets for enhanced noise reduction | – |
| Bindings | Siegenia-AUBI TITAN: ◆ Protected with “TitanSilber” silver-coloured anti-corrosion coating ◆ Hinges with Teflon bushings for smooth and effortless window operation ◆ Equipped with white hinge covers. |
◆ Various functional hardware accessories (opening restrictors, handle operation limiters, multi-stage micro-ventilation) ◆ Concealed hinges |
| Burglar-resistance level |
One corner of the sash is equipped with standard anti-lift protection. |
Up to RC2 security class |
| Ventilation | Micro-ventilation | Ventilation accessories – horizontal air vents installed in the glazing unit or milled into the window frames, and multi-stage micro-ventilation. |
| Security | – | ◆ Aluminium threshold protection for balcony doors ◆ Handle misuse prevention device for tilted window sashes ◆ Handle misuse prevention device for open balcony door sashes |
| Handles | ALU, white colour | Exterior handles and latches for balcony doors, safety handles, handle covers, and child safety accessories. |
